TRX-95096-4-GRN Traxxas 1/8 Sledge Belted - Green

Traxxas Sledge

Model Overview

MODEL 95096-4: Sledge 1/8 scale 4WD brushless monster truck. Fully assembled and Ready-To-Race®, featuring:

• TQi™ 2.4GHz radio system
• VXL-6s brushless power system
• Belted Sledgehammer® tires
• ProGraphix® clipless body

---

What’s In The Box:

• Sledge, Ready-To-Race® monster truck with Traxxas 2000 kV brushless motor
• VXL-6s waterproof electronic speed control with integrated telemetry
• Quick Start Guide
• TQi 2.4 GHz radio system
• High-quality maintenance tools
• Jumper plug (for 4s battery use)

---

Recommended Batteries:

• Dual 5000 mAh 3-cell 11.1 V Power Cell LiPo batteries for maximum performance.
• Dual 7600 mAh 7.4 V LiPo batteries or a single 6700 mAh 14.8 V LiPo battery will operate the vehicle with reduced performance.
• NiMH batteries are not supported.

---

Recommended Charger:

• EZ Peak Live Dual 3s LiPo Charger with iD®

---

Additional Requirements:

• Four AA alkaline batteries for the transmitter.

---

Key Features:

VXL-6s™ Waterproof Electronic Speed Control

• 6s LiPo compatible
• Integrated cooling fan
• Real-time telemetry via Traxxas Link™
• 3-LED status indicators
• Powered accessory ports
• 10-gauge silicone wire
• Integrated protection circuits

Velineon® 2000 kV Brushless Motor

• 4-pole 2000 kV
• 5 mm output shaft
• Finned can for better heat dissipation
• Aluminum motor cradle mount
• Supports the entire motor length to reduce flex and extend gear life

Performance

• Achieves up to 70+ mph with two 3s LiPo batteries (sold separately).

---

Stability and Control

Traxxas Stability Management®

• Helps prevent spinouts and loss of control.
• Never dulls throttle or slows the truck.
• Adjustable assistance from off to 100% via the transmitter.

TQi™ 2.4 GHz High Output Radio System

• TQi 2-channel transmitter, Traxxas Link enabled.
• 2.4 GHz 5-channel micro receiver (6533) with fail-safe security and integrated telemetry ports.
• Automatically stores and loads settings for up to 30 Traxxas Link-enabled models—no “model selection” required.
• Programmable Multi-Function knob.
• Adjustable steering and throttle percentage (dual rates).
• Adjustable steering and throttle sensitivity (exponential).

---

Drivetrain

• Full-time 4-wheel drive
• Heavy-duty steel driveshafts
• Large 8 mm steel stub axles
• Steel dogbone center driveline
• Protective rubber boots on differential inputs

Transmission

• Mod-1 pinion and spur gears
• Fixed gear mesh system
• Torque-Biasing Center Drive

Differentials

• Heavy-duty sealed 4-gear design
• Large-scale steel ring and pinion gears
• Large 8 mm output shafts
• Steel drive cups
• Easy access bulkheads

---

Suspension and Shocks

GT-Maxx® Shocks

• Longer rear shocks for more travel
• Machined aluminum threaded body
• Extra-large bore and capacity
• Large-diameter damper shaft
• Lower seal cartridge with dual X-rings
• Height-adjustable spring retainer
• Lower spring perches bolted on

Suspension

• Thick 5 mm 6061-T6 aluminum shock towers
• Ultra-tough composite arms made from the strongest cold-weather material
• Molded insert for a clean look
• Rear rock deflectors
• Press-in hinge pins to reduce play
• Oversized molded toe and camber links
• Heavy-duty C-hubs with oversize bearings
• Multiple mounting points for suspension tuning

---

Chassis

• 3.2 mm ribbed aluminum chassis with formed edges for improved strength
• Thick aluminum T-Bar™ for added rigidity
• High-strength buttressing on shock towers
• Rugged locking battery compartment with quick-release door
• Low-CG design for improved handling
• Interlocking components for tight tolerances
• Tough front and rear bumpers double as skid plates
• Hidden wire management for a clean appearance

---

Body Design

• Clipless ProGraphix® Body with a one-handed clipless body mounting system
• Rigid internal frame
• Molded body reinforcements for tear-through protection
• Protective roof skids
• Rugged high-downforce rear wing

---

Steering

• Waterproof 2275 metal gear servo with 347 oz-in torque
• High-throw bellcrank steering design
• Heavy-duty servo saver with aluminum posts
• Metal servo horn

---

Wheels and Tires

• Massive 6.7″ Sledgehammer all-terrain tires with a belted carcass to resist ballooning
• Tough 3.8″ black wheels
• Splined 17 mm aluminum axle hubs
