KYO-32523IV Kyosho Mini-Z 4x4 Suzuki Jimny Sierra Readyset - Chiffon Ivory Metallic

What It Is

The Kyosho MINI-Z 4x4 is a 1:28 scale radio-controlled mini crawler based on the Suzuki Jimny Sierra — one of the most beloved compact 4x4 trucks ever built. Everything fits in the palm of your hand, but the engineering underneath is anything but small.

Key Features

• Ladder frame chassis with steel vertical plates — same design principle as real 4WD off-road vehicles
• 3-link rigid axle suspension front and rear — full articulation for genuine crawling performance
• Adjustable wheelbase: 120 mm (Jimny Sierra setting) or 110 mm via spacer change
• 130-class high-torque motor tuned for low-to-medium speed crawling
• Swappable pinion gear set (10T through 20T) — speed range approximately 2.7 to 5.4 km/h
• BFGoodrich Mud-Terrain T/A KM3 scale-replica tires on Suzuki factory-replica silver wheels
• KT-531P Syncro 2.4GHz FHSS transmitter — steering/throttle trim and dual-rate steering adjustment
• Factory-painted injection-molded body with fine detail: mirrors, wipers, windshield washers, rain rails, door hinges
• Accessory ports for optional gyro (MZW431) and LED light set (MZW429R)
• Approximately 60-minute run time

What's Included

• Complete MX-01 chassis with built-in electronics
• Factory-painted Jimny Sierra body — Chiffon Ivory Metallic
• KT-531P 2.4GHz transmitter
• Pinion gear set: 10T, 12T, 14T, 16T, 18T, 20T
• 3 types of pinion gear spacers

You Also Need

• 4× AAA alkaline batteries for the chassis (not included)
• 4× AAA alkaline batteries for the transmitter (not included)

Specs

• Scale: 1:28
• Chassis: MX-01
• Length: 193 mm · Width: 84 mm · Height: 90 mm
• Wheelbase: 120 mm (adjustable to 110 mm)
• Weight: 242 g (excluding batteries)
• Motor: 130-class
• Speed: approx. 2.7–5.4 km/h (pinion-dependent)
• Run time: approx. 60 minutes
• Transmitter: KT-531P Syncro 2.4GHz FHSS

Reference Numbers

32523IV / KYO32523IV / KYO-32523IV · UPC 4548565385973
